Teaching a CUDA Engine to Speak Metal
Most of the Apple-Silicon ports I’ve written up are the same fight in different costumes: take a PyTorch project that assumes an NVIDIA card is bolted under the desk and talk it down to MPS . That’s a porting job. The GPU support already exists; you’re just stopping the code from hardcoding the wrong god.
This was a different animal, and I want to be clear about that up front because it changes how impressive - or not - the whole thing is. CTranslate2 isn’t a PyTorch project. It’s a from-scratch C++ inference engine with its own tensors , its own memory allocator, its own CUDA kernels. It has no “GPU device” abstraction you can just point at Metal . So the job wasn’t “port a model.” It was “add a third GPU backend to an engine that has exactly two - CUDA and CPU - and was architected by people who reasonably assumed those were the only two that would ever matter.”
That sounds like a research project. It mostly wasn’t, and the reason it wasn’t is one fact about Apple Silicon that does almost all the work. The rest of the series is the part that one fact didn’t do for free.
The disclosure, because it’s the whole point and not the fine print: I have never written a line of C++. Not for this, not ever. The last C I touched was for Harvard’s CS50, and given a patient afternoon and Stack Overflow I could maybe flip an array. On paper there is no way I’m qualified to read this engine’s source, let alone bolt a GPU backend onto it.
So I didn’t read it. I directed agents that did - armed with a couple of skills I built for the
job and a plan I sketched in about ten minutes - and I judged the results by what came out the
far end: is this transformer producing the right tokens, or isn’t it. That’s a black-box
judgment, a behavioral one, not a line-by-line one. So when a post in this series says “I wrote a
kernel” or “I clamped the tanh,” read it the way a general contractor says “I built that house.”
I didn’t lay a single brick. I knew what finished was supposed to look like, I knew which wall was
crooked, and I knew who to send back to fix it. The bricklaying - every line of it - was the
agent’s.
The “couple of skills” are quietly doing most of the work in that sentence. An agent that knows more C++ than I ever will is also an agent that will, with total confidence, reach for a shader function that does not exist or lay a matrix out the wrong way round and hand me a NaN three sessions later. The fix was not to trust its memory. It was to build it a map. Two of them: one charting CTranslate2’s own architecture - how an op is structured, how a tensor is laid out, where the norm goes - and one charting Apple’s Metal, the GPU dialect the engine had never been introduced to. Every entry is pinned to a primary source, the actual header or the actual Apple doc, and a small script audits whether those citations still point where they claim to. The missing math function that becomes its own war story a few parts from here was already a flagged landmine in that second map before a single kernel went wrong.
Which is the plain answer to “how can you vouch for code you cannot read.” You cannot, not line by line, so you stop leaning on anyone’s memory, yours or the model’s. You make the map cite its sources, you check that the citations still hold, and you judge the finished building by whether it stands. The two reference maps are the part of this whole project I would actually hand to the next person trying the same trick on a different engine.
That division of labor isn’t a footnote here; it’s the subject. It’s why this is a writeup and not a pull request, and Part 7 is about exactly that - because the codebase is the kind where, as its own maintainers put it, “a single misplaced pointer can take hours to debug,” and the gap between “I can explain what this does” and “I can vouch for this line” turns out to be the whole story.
Where it got to
A full encoder-decoder transformer runs end-to-end on Metal, in both 32- and 16-bit float, producing token-for-token the same output as the CPU - GPT-2-style and Llama/Mistral-style architectures both. The whole per-token forward pass executes as real GPU kernels: matmuls on Apple’s MPS library, plus hand-written Metal kernels for softmax, the normalizations, rotary embeddings, gather, fused bias-and-activation, and elementwise math. Everything not yet on the GPU runs correctly on a CPU-reference path over shared memory, behind a full regression net.
It is correct, it is memory-safe, and - the part I won’t oversell - for some workloads it is still slower than the CPU, for reasons that turn out to be the most interesting thing in the whole project. That unglamorous middle is what the seven parts below are about.
The series
Read them in order or cherry-pick a war story - Parts 4, 5, and 6 each stand alone as debugging stories. Each links back to the glossary where a term needs unpacking.
- Part 1 - The Cheat Code: Unified Memory
The one fact about Apple Silicon that turns 'add a whole new GPU backend' from a research project into an afternoon: the CPU and GPU share the same RAM, so a GPU buffer is also a CPU pointer - and CTranslate2's entire internal contract is built on pointers.
- Part 2 - The Staircase: Graduating Ops One at a Time
How to turn 'make the whole engine fast' from a cliff into a staircase: bind the new Metal device to run the CPU code, get a correct engine for free, then move ops to real GPU kernels one at a time - each one a small diff against a green test suite. Plus the two tiny exceptions that hold the entire trick up.
- Part 3 - The Small Indignities of Metal Shading Language
Once you're graduating ops you're writing kernels in Metal's own C++-flavored shader language - and discovering its personality. The free gift (MPS matmul is laid out exactly how CTranslate2 already thinks), the missing math function that doesn't exist in any version, and why the kernel library compiles itself lazily on purpose.
- Part 4 - The NaN That Ate Three Sessions
A real model - Gemma2 - ran on the Metal backend and produced one correct token, then collapsed into <pad> forever. None of the kernels were 'wrong.' The bug was a library tanh that's fine on the CPU and quietly returns NaN on the GPU, and finding it meant killing three sessions' worth of beautiful, wrong theories.
- Part 5 - The 730-Second File: A SIGKILL That Wasn't a Leak
Whisper on the Metal backend died on a twelve-minute audio file - killed by the OS at the 155-second mark, memory climbing the whole way. Every obvious leak theory was wrong: the process heap was flat. The real culprit was an Objective-C convention nobody thinks about until it kills you, and the real perf result at the end isn't a win.
- Part 6 - Profile, Don't Guess
Where the Metal backend actually gets fast, where it doesn't, and three times the intuition was dead wrong: a 16-bit op that was secretly 27× slower because it had never been on the GPU, the 'obvious' optimization that made things worse when measured, and a benchmark number that swung 2.7× between identical runs.
- Part 7 - The Thing This Didn't Become: A Pull Request
There's a working Apple-Silicon GPU backend at the end of this, built by someone who has never written a line of C++. It is not going upstream as one big pull request, and the real reason is the most interesting lesson in the project - about what 'understand it and defend every line' means when the line-level understanding genuinely isn't yours, and why a fork is the right home, not a consolation prize.
