Part 6 - Profile, Don't Guess

↑ Teaching a CUDA Engine to Speak Metal

Part 5 ended on an uncomfortable fact: for Whisper, the GPU backend loses to the CPU. This part is about why that’s true for some workloads and gloriously false for others - and about the three times I was confidently, measurably wrong about which was which. The through-line, if you want it on a sticky note: profile, don’t guess. Every single time I guessed, I was wrong, and the profiler was right.

Where the GPU wins: big matmuls

Start with raw matrix-multiply throughput, because it sets up everything else. Square matmul, GPU 16-bit float versus the Apple CPU’s tuned math library:

The shape of that table is the whole story of GPU acceleration. At small sizes the CPU wins easily, because each GPU call pays a fixed overhead - commit a command buffer, set up the matmul object, wait - and a small multiply is too little work to amortize it. Every GPU call costs the same to set up whether there’s a little work waiting or a lot of it. It’s the ladder in the garage: hauling it out, extending it, and putting it back takes four minutes no matter what, so changing one bulb is almost entirely ladder. Change forty while you’re up there and the ladder stops mattering. Size 2048 is forty bulbs. At size 2048 the GPU is 3.7× faster and it’s a stable, repeatable result. The math hardware is genuinely strong; you just have to give it enough to chew.

A measurement caveat. The size-1024 row - right at the crossover - swung between 0.85× and 2.26× across four back-to-back runs on the same machine. A 2.7× spread on identical inputs. It straddles the point where dispatch overhead stops dominating but the GPU isn’t saturated yet, so one unlucky iteration skews the average. I report 2048 as the first dependable win and treat 1024 as a coin flip - because quoting the lucky draw would be exactly the guessing this part is against.

Wrong guess #1: the 16-bit op that was never on the GPU

Here’s the one I’m fondest of, because the intuition was so clean and so wrong.

On a real LLM (Qwen2.5-0.5B), 16-bit prefill came out slower than 32-bit. That looks diagnostic: 16-bit is supposed to be the fast path on Apple hardware, so if it’s slower, MPS’s 16-bit matmul must be weak, right? Reasonable. Wrong.

The profiler said the matmuls were identical in both precisions. The entire regression was a single elementwise Add - the residual connection - and in 16-bit it had exploded 27×. The cause had nothing to do with precision math: the Add op had never been wired to its GPU kernel. On paper it was a GPU op. In the actual building it was an extension cord running out a window to the neighbor’s garage, which is fine, and stays fine, right up until you plug in something that actually draws power. It was quietly running on the CPU reference the whole time - fine in 32-bit (fast vectorized CPU math), catastrophic in 16-bit (slow software-emulated half-precision), and forcing a pipeline stall on every single residual, dozens of times per forward pass.

Routing Add to a real GPU kernel - a kernel that already existed, from the very first milestone, and had simply never been connected - dropped 16-bit batched prefill from 1815ms to 559ms. A 3.2× jump that made the GPU 2.6× faster than the CPU and 4× faster than its own 32-bit path. This is where Apple Silicon gets fast. And I’d never have found it by reasoning about MPS, because MPS was never the problem. The problem was an op that looked GPU-resident on the architecture diagram and wasn’t in the actual code.

Wrong guess #2: the optimization everyone reaches for first

Every op currently commits its own batch of GPU work. The textbook optimization is obvious: stop doing that, batch many ops into one submission per decode step, pay the per-commit overhead once instead of dozens of times. It’s the first thing anyone suggests, so I had it built - fully, every cross-thread-ordering corner handled, and it passed every parity test.

Measured: neutral on the workload it was supposed to help, and a 23% regression on the matmul-heavy ones. So I reverted it.

The reason is the kind of thing you only learn by measuring. Committing each op separately isn’t waste - it’s what lets the GPU run op N while the CPU is busy encoding op N+1. That overlap is free parallelism. Two people doing the dishes: hand each plate over as you wash it and the towel never stops moving. Decide instead that handing plates over one at a time is inefficient, wash the entire sink first, and now somebody is standing there holding a dry towel, waiting, while you save four seconds on handoffs. Batching everything into one big commit per step destroys it: the GPU sits idle until the whole batch is submitted, and for matmul-heavy work the lost overlap costs more than the saved commit overhead ever saved. The “obvious” win was a real loss. Per-op commit was already near-optimal, and the commit count was never the bottleneck I assumed it was.

What actually helps: fewer, bigger ops

The lever that did work isn’t doing the same work with less overhead - it’s doing less work. Op fusion: instead of a separate residual-add and then a normalization, one fused kernel that reads the inputs once, writes the residual sum, and writes the normalized result in a single pass. One fewer kernel launch, one fewer trip through memory. It isn’t running the same errands faster. It’s one trip to the store instead of two. Measured a real, repeatable ~1.25-1.3× at the mid-size shapes that match actual LLM hidden dimensions - and crucially it helps without killing the CPU/GPU overlap, because it reduces op count rather than batching commits. Fewer, bigger ops is the right direction; fewer commits was a mirage.

The shape of it: prefill wins, decode loses

Putting it together explains Part 5 ’s Whisper result precisely. There are two regimes:

• Prefill - processing a whole prompt at once - is big matmuls, the favorable end of that first table. The GPU wins, and in 16-bit it wins big.
• Decode - generating one token at a time - is a long stream of tall-skinny matrix-vector products, each tiny, each paying the GPU-dispatch toll. The CPU wins, because it has no dispatch toll to pay. Having 500 million parameters doesn’t save you; each step still issues many small ops.

Whisper is decode-bound, so Whisper loses. A throughput-bound batch-translation workload is prefill-heavy, so it wins. Same backend, opposite verdicts, and the only way to know which you’re looking at is to measure it - not to reason from the parameter count or the precision or the TFLOPS the hardware can theoretically hit.

Three wrong guesses, three corrections, one moral: the intuitive culprit is a hypothesis, not a finding. The profiler is the finding. (And the difference between making a model smaller by dropping precision versus by quantizing it - which I leaned on throughout - is the precision entry, since it’s the single most common thing people get backwards about all of this.)

That’s the technical arc. There’s one question left, and it’s not a technical one: a working GPU backend exists - so why is it living in a fork and a blog post instead of the upstream project? Part 7 .
