Part 4 - The NaN That Ate Three Sessions

July 15, 2026

Everything in Part 3 ended with a transformer producing token-for-token the same output as the CPU. Then I pointed it at a real, full-size model - Google’s Gemma2-2b - and it produced this:

CPU   fp32:  2019 - 2020 school year is off to a great start! ...
METAL fp32:  ▁ <pad> <pad> <pad> <pad> <pad> <pad> <pad> <pad> ...   (forever)

The first generated token always matched the CPU. Every token after it collapsed to <pad>, identically in 32-bit and 16-bit float. The same model on the CPU produced fine, coherent text. And (the detail that should have saved me a session and didn’t) Qwen2.5-0.5B decoded perfectly on Metal, both precisions, 24 tokens out of 24 matching the CPU. So whatever this was, it was specific to Gemma2.

This took three sessions. Most of that time was spent being confidently wrong, so let’s do the wrong part first, because the wrong part is where the transferable lessons live.

A pink-and-teal risograph print: a detective with a magnifying glass follows a trail of numbered tiles that ends at a black hole in the floor, three calendar pages hanging nearby. — The trail is fine right up to where it isn’t.

Three sessions of beautiful, dead suspects

A model that emits one good token and then jams on a single repeated token is a siren song for plausible theories. Gemma2 has a bunch of distinctive architectural quirks, and I investigated and killed every one of them:

Suspect	Why it was tempting	Why it was wrong
`final_logit_softcapping`	Gemma2 caps its logits; a missing cap could wreck the argmax	The CT2 converter doesn’t even set it - and it runs fine on unified memory anyway
`attn_logit_softcapping`	Same family, applied before softmax	Not implemented in CT2 at all - a feature missing from both CPU and Metal can’t cause a CPU-vs-Metal split
Sliding-window attention	The one Gemma2-shaped attention oddity	The converter never sets it per layer (that’s Gemma3); the window can’t even fire under 4096 tokens
`query_pre_attn_scalar`	Differs from the usual attention scaling in general	Defaults correctly for the 2b size
The whole `(1+γ)` RMSNorm stack	Gemma2-distinctive, feels suspicious	Exonerated by the trace below - the first 22 layers are byte-identical to the CPU

A grainy amber photograph of a dark workshop bench under one hard lamp: three identical machines lie side by side, each stripped completely down to its parts, every plate and screw and fastener laid out in neat rows beneath its own emptied carcass. — Every part accounted for. None of them did it.

Lesson one: read the converter, not the model card. Three of those five died the instant I read what CTranslate2’s Gemma2 converter actually writes into the model, versus what HuggingFace Gemma2 has. The “Gemma2 features” you’d reach for from memory are not all in the converted model. I was debugging a model that existed in my head, not the one on disk.

Lesson two: “it runs on step 1 too, so it can’t be the cause” is a weak argument. My prime suspect got demoted with exactly that reasoning - soft-capping runs on the first token too, and the first token is correct, so it’s exonerated, right? It happened to point the right way here. But the logic is bad: an op that’s wrong-but-not-yet-catastrophic can produce a correct argmax on step 1 and a NaN on step 2. Don’t reason about it. Get data.

How it was actually found

Localize at the boundaries

I added environment-gated tripwires - per-layer checksum and NaN dumps, switched on with an env var so they cost nothing in normal runs - and watched where the numbers first went bad. The decisive readings, all at decode step 2 (the token that collapses):

Steps 0 and 1 match the CPU exactly. The divergence is born at step 2.
Decoder layers 0 through 22 are byte-identical, CPU versus Metal - sum and max-abs both.
Layer 23’s output is NaN (the CPU’s is finite). That NaN then propagates: final norm goes NaN, the logits go NaN, argmax of all-NaN falls to index 0 - which is <pad> - and the model jams there forever.

So it’s not the whole model. It’s one layer, at one step, going NaN.

The trap inside the trap

Naturally I tried to pin the NaN to a specific operation inside layer 23 by reading each op’s output back to the CPU. And every GEMM read back as all-NaN - including prefill GEMMs that demonstrably produced the correct first token. Even with an explicit synchronize before the read.

Lesson three, and it’s a nasty one: on this backend, a CPU read of a freshly-committed MPS matmul output is not reliable. Ops commit asynchronously, and the flush I had did not make that specific just-committed result visible to a CPU read in that context. Layer-boundary reads, after the layer’s last committed op, are reliable, which is why the per-layer trace was trustworthy while the per-op probe was garbage. I spent real time chasing NaNs that were reading artifacts, not real state. Debug Metal numerics at boundaries, not with raw post-op probes.

Bisect by forcing ops to the CPU

Here’s where the Part 2 architecture pays a debt. Because the CPU reference runs correctly on Metal’s unified memory, I can force any single op family back to the known-good CPU path and A/B it cleanly:

Experiment	Result	Conclusion
Zero the GEMM output buffer before MPS	still collapses	not a stale-buffer issue
Synchronize after every GEMM	still collapses	not a simple async-GEMM race
All matmuls → CPU reference	still collapses	MPS matmul is innocent
GELU activation → CPU reference	24/24, fixed	the Metal GELU kernel is the bug

That last row is the whole ballgame. With the GELU activation running on the CPU, Gemma2 decodes perfectly. With it on the Metal kernel, it collapses. After three sessions of architecture theories, the culprit was the dumbest, most fundamental box in the building.

The actual bug: a `tanh` that lies

The GELU-tanh kernel computes 0.5 · v · (1 + tanh(u)), where u is roughly proportional to v³. And Metal’s tanh(x) is implemented as (exp(2x) − 1) / (exp(2x) + 1).

Look at that for large x. exp(2x) overflows to infinity, and then you’re computing Inf / Inf, which is NaN. Mathematically tanh should just saturate to ±1 for large arguments - and the CPU’s std::tanh does exactly that. Metal’s version overflows on the way to a value it already knows.

This explains every single facet of the symptom:

Gemma2-specific: Gemma2 is famous for large, growing deep-layer activations - and the CT2 converter ships no soft-capping to tame them. By layer 23 the gate pre-activation is big enough that u ~ v³ overflows tanh’s internal exp. Qwen’s activations never get that big.
Layer 23, step 2: the deepest, largest activations, at the first step where the value crosses the overflow threshold.
Identical in fp32 and fp16: it’s an argument-magnitude overflow, not a precision problem
- which is the tell that this had nothing to do with 16-bit math (see precision for why those are different failures).

The fix is ten lines. tanh saturates to ±1 long before its argument can overflow the internal exp, so clamp the argument: tanh(±15) already equals ±1.0 in 32-bit float, and exp(30) is nowhere near the ceiling. The clamp is a no-op for any value below 15, so it’s numerically exact in the entire meaningful range - normal-range GELU and small-activation models like Qwen are provably untouched. We just stop feeding exp numbers it can’t hold.

One last gotcha, because it nearly faked a pass

A meaningless or BOS-less prompt makes both backends degenerate into the same repetitive loop, so CPU == Metal holds true on garbage, and a naive parity test false-passes. Gemma2 needs a real, model-appropriate prompt with its leading <bos> token, or the test agrees that two broken things are identical. Gate your correctness checks on real inputs, never filler.

Five transferable lessons, then, from one ten-line fix: read the converter not the model card; don’t trust “it runs on step 1” reasoning; mid-pipeline GPU reads lie, so trust boundaries; CPU-reference bisection over unified memory is the highest-signal tool you have; and tanh/exp on a GPU are overflow traps wearing the costume of functions you trust.

That was a correctness bug. The next one looked exactly like a memory leak, wasn’t, and killed a twelve-minute audio file at the 155-second mark. Part 5 .
