Part 2 - The Staircase: Graduating Ops One at a Time

↑ Teaching a CUDA Engine to Speak Metal

Part 1 ended with a gift: because Metal memory is also CPU memory, the existing CPU code runs correctly on GPU-resident data, so the engine is correct before a single kernel is written. This part is about cashing that gift without setting it on fire.

The trap you’d walk into first

CTranslate2 decides where to run an operation through a big dispatch switch on the device. Conceptually: “if CUDA , run the CUDA kernel; if CPU, run the CPU kernel.” The obvious way to add Metal is to bolt on a third arm - “if Metal, run the Metal kernel” - and then go write a Metal kernel for all ~50 operations before anything runs at all.

That’s the research-project version, and it’s a trap with teeth. The engine is built on C++ templates, and adding Device::METAL as a real dispatch case forces the compiler to instantiate a Metal implementation of every primitive at roughly fifty call sites - just to compile and link. Not to run. To link. You’d be staring at fifty linker errors before you could produce a single token, and the only way to clear them is to write fifty kernels on faith, with nothing running to tell you which ones are wrong.

The move: bind Metal to the CPU

The cheat code unlocks something much better. In the dispatch switch, I bound the Device::METAL case to run the CPU implementation - literally constexpr Device D = Device::CPU inside the Metal arm. Because Metal memory is CPU-addressable, the CPU kernels are correct on Metal-resident data. So with that one binding, the entire engine runs on Device::METAL immediately - every op, every layer, a whole transformer - with zero Metal kernels written and zero of those fifty template instantiations demanded.

Slow, obviously. It’s the CPU doing the math while the data happens to live in GPU-visible memory. But correct - and here’s the payoff that makes everything after it safe: the existing op, layer, and storage test suites now run against the Metal device and pass. I had a regression net before I had a single GPU kernel. Every later move gets checked against it.

Graduating ops: targeted routing

Now the GPU work becomes incremental instead of all-or-nothing. Pick a hot operation - matrix multiply, say. Write the Metal version. Then add one check at the very top of that op:

#ifdef CT2_WITH_METAL
if (a.device() == Device::METAL) { metal::gemm(...); return; }
#endif
// ...otherwise the original CPU/CUDA dispatch, untouched

That’s the whole pattern, and its boringness is the point. The op checks the real device, which is still honestly Device::METAL even though the dispatch bound D = CPU, and if the data really is on the GPU, it calls the real kernel and returns. Everything else still falls through to the CPU reference. The test suite confirms the new GPU kernel produces the same numbers as the CPU code it just replaced.

I called this “graduating” an op, and the forward pass got graduated one box at a time: GEMM, then softmax, then the normalizations, then rotary embeddings, gather, the fused bias-and-activation, elementwise multiply, the residual add, the KV-cache concat. Each one a small, independently-verifiable diff against a suite that’s green before and after. You are never more than one op away from a working engine.

This is the part I’m actually proud of, and notice it’s an architecture idea, not a kernel trick. The hardware gave me “correct but slow” for free; the dispatch binding turned “make it fast” from a cliff into a staircase. Nobody ever has to stand at the bottom of fifty kernels and jump.

The two steps that must NOT follow the rule

Every clean trick has one exception that holds the whole thing up, and skipping this one is how you donate a Saturday to a debugger.

“Bind Metal to run the CPU code” is exactly right for math. It is exactly wrong for two specific things: allocating memory and answering “which device am I?” If those follow the CPU binding too, then when the engine asks for memory on the Metal device it gets plain CPU memory - not a shared Metal buffer. Now the data is not in a buffer the GPU can name, and the moment a real kernel goes looking for its operands via that allocator side table from Part 1 , it finds nothing. The whole illusion collapses, silently, one layer away from where the bug looks like it lives.

So the allocator lookup and the device-index resolution early-return for Metal before the dispatch trick can grab them. These two specifically do not fall through to CPU; they go to the real Metal allocator and the real Metal device. It’s two small exceptions to an otherwise total rule, and in the repo they’re flagged as load-bearing in capital letters, because they look deletable and they are the opposite of deletable.

That’s the architecture: one binding that makes everything work slowly, two exceptions that keep the fast path findable, and a staircase between them. Next we actually climb it - and meet the Metal Shading Language’s personality (Part 3, landing here in a few days), which has some opinions about which math functions get to exist.
