Part 1 - The Cheat Code: Unified Memory

↑ Teaching a CUDA Engine to Speak Metal

Here’s the fact the entire design hinges on. On Apple Silicon the CPU and GPU share the same physical RAM. When you allocate a Metal buffer with “shared” storage, you get back a pointer that the CPU can read and write directly - and the GPU can use the same buffer. There’s no “copy the data over to the GPU” step, because there’s no “over.” It’s all one pool.

On an NVIDIA box this is not true. The GPU has its own separate memory across a bus, and half of GPU programming is the bookkeeping of shuttling data back and forth and not doing it more than you have to. CTranslate2’s whole internal contract is built around that world: a tensor is “a pointer plus a shape,” and there’s an allocator whose job is to hand out memory the GPU can use.

Now watch what unified memory does to that contract.

CTranslate2 wants a pointer the GPU can use. A shared Metal buffer is a pointer the GPU can use - and the CPU too. So if I make the allocator hand out Metal buffers instead of plain CPU memory, every piece of existing CPU code in the engine suddenly works on GPU-resident data, unchanged. Not ported. Not rewritten. It just works, because the pointer it’s holding happens to live in memory the GPU can also see.

That’s the cheat code. It means I didn’t have to start by writing kernels. I had to start by writing an allocator - and then I got a working (if slow) Metal engine for free, running the existing CPU reference code over GPU memory. Correctness first, speed later, and the “free” part is a gift from the hardware.

The allocator is the whole trick

The real work of Part 1 is one file, src/metal/allocator.mm. It specializes CTranslate2’s allocator for the new Device::METAL. Each allocation becomes an MTLBuffer with shared storage; the allocator returns [buffer contents] - the CPU-addressable pointer into that buffer - and that pointer satisfies the existing pointer-based contract with nothing else changed. Host-to-device copies, which on CUDA are a whole cudaMemcpy ceremony, collapse into a plain memcpy, because both sides are the same memory.

There’s exactly one wrinkle, and it’s the kind of thing that’s invisible until it isn’t. CTranslate2 doesn’t only hand around pointers to the start of an allocation. It takes sub-views into a tensor, and strided-batch GEMM hands the matrix-multiply routine pointers that land in the middle of a buffer. Metal, though, wants to bind the buffer object, plus a byte offset - it can’t take a raw interior pointer and work out which buffer you meant.

So the allocator keeps a side table: an address-ordered map of every allocation it’s handed out. When some op shows up later holding an interior pointer, a range lookup (buffer_and_offset) walks that map, finds the allocation the pointer falls inside, and hands back the owning MTLBuffer plus the offset. It’s a small piece of bookkeeping that exists entirely to translate between CTranslate2’s “everything is a raw pointer” worldview and Metal’s “name me a buffer” worldview. (And it’s manual retain/release, not ARC - the .mm files manage their own Objective-C object lifetimes throughout, which becomes its own story later in this series.)

What “for free” actually buys you

The temptation, when you set out to add a GPU backend, is to think the deliverable is kernels: the hand-written GPU programs that do the math fast. And eventually it is. But the cheat code reframes the whole project. The first deliverable isn’t speed; it’s a correct engine that happens to be slow, standing up on day one, with the entire existing test suite passing against the new device.

That matters because it inverts the usual order of pain. The normal way to add a backend is to write fifty kernels and then spend weeks finding out which three of them are subtly wrong. The cheat code lets you stand up “correct but slow” first, then make it fast one piece at a time, with a green test suite watching your back the whole way. You’re never debugging “is it broken because the math is wrong or because the plumbing is wrong” - the plumbing was proven correct before any math moved to the GPU.

How you go from “correct but slow” to “fast, one op at a time” without ever breaking that green test suite is the actual architecture of this thing - and it’s Part 2, landing here in a few days.
